Voltage Regulator are widely used in areas with unstable grid voltage. They automatically stabilize the output voltage to ensure the normal operation of household appliances, precision instruments and industrial equipment, and prevent failures or damage caused by voltage fluctuations.
Showing all 6 results
Input voltage：single-phase，150-250VAC
Output voltage VAC：220±10%
Frequency：50Hz/60Hz
Efficiency：＞90%
Overvoltage protection：246±4V
Delay (output) time：long delay:5min士2min，Short latency:(3~10)s
Ambient temperature：-5°C~+40°C
Insulation resistance：≥5MΩ
Pressure Resistance：Withstand 1500V for 5 seconds without breakdown or flashover (leakage current ≤ 25mA)
Input voltage VAC：single-phase：45V~280V / 100V~260V / 150V~250V
Output voltage VAC：220±10%
Frequency：50Hz/60Hz
Efficiency：≥92%
Overvoltage protection：246±4V
Delay (output) time：long delay:5min±2min，Short latency:(3~10)s
Ambient temperature：-5°C~+40°C
Insulation resistance：≥5MΩ
Pressure Resistance：Withstand 1500V for 5 seconds without breakdown or flashover (leakage current ≤ 25mA)
Input voltage ：3P4W system，300-456VAC
Output voltage：3P4W system，380VAC
Output precision：1%-5% adjustable
Efficiency：95% Power above 50kVA
Protection function：Overpressure, overcurrent, phase loss,phase sequence
Input Voltage ：single-phase（150~250）VAC
Output voltage：220V±3%，110V±3%
Frequency：50/60Hz
Efficiency：＞90%
Response time：<1s，when input voltage changes by 10%
Rated capacity：（0.5~30)kVA
Input Voltage ：there-phase（260~430）VAC 3P4W system
Output voltage：380V±3%，3P4W system
Frequency：50/60Hz
Efficiency：＞95%
Response time：<1s，when input voltage changes by 10%
Rated capacity：（3~100)kVA
